Migration from PostgreSQL v.9.6 to v.12.11 with minimum downtime

8 min read

About a year and a half ago we had the following situation: we used PostgreSQL version 9.6 as a database, which was hosted on AWS RDS. Despite the fact that version 9.6 was quite old (PostgreSQL v.14 had already been released that year), we constantly postponed migration, because this process is quite demanding. Everything was further complicated by the size of the database itself – about two terabytes.

At a certain point, there was no time to postpone the update: AWS RDS stopped supporting our version of the base. Within a certain time, we had to update our database version from 9.6 to 12.11, otherwise AWS RDS would update it automatically after the deadline. We weren’t happy with this option, as it implies stopping the application, and in our case it could take hours, which is completely unacceptable for us.


We faced the following challenge: the need to migrate from PostgreSQL 9.6 to PostgreSQL 12.11 with minimum application downtime. The main difficulty was that the internal format of data representation on the hard drive is changed between the major versions in PostgreSQL, which in turn leads to a lack of backward compatibility between major versions of PostgreSQL. This means that when you update a major version of PostgreSQL, you must also update all the data. Accordingly, the more data in the database, the more work must be done when updating it.

08.06 Migration from PostgreSQL v.9.6 to v.12.11 with minimum downtime img 1 development


Keeping that in mind, we started looking for a solution. The easiest way was to use the command pg_dump. This command allows you to make a snapshot of the database in text format, which then can be executed using the command psql

For this purpose a new base is created with an updated version in which the snapshot is completed. This approach, however, has a significant disadvantage – it takes a long time to work with large amounts of data. Since pg_dump captures the initial state in the beginning of making a snapshot, data in the database becomes outdated by the end of the process. Moreover, once the snapshot is done and the data transfer has started, the application can no longer use neither the original database, nor the new one until the transferring process is completed. Thus, the application must be stopped both during the completion of the snapshot and during its application. As already mentioned, the commands, pg_dump and psql are quite slow, which can lead to a downtime.

Another more preferable approach is to use the pg_upgrade command. It was created specifically to migrate data between databases and update major versions in the most efficient way. Despite quite good performance in synthetic tests, we have decided not to use this command because it also requires the application to stop during the data migration, and there is no guarantee that the data migration will work out in time.

Having dropped these options, we decided to look at data migration using data replication. The general scheme of such migration is the following:

  1. A new database (replica) with a new version is created;
  2. The replica is connected to the source database (source or master);
  3. Data is asynchronously migrated from the source to the replica;
  4. When the data in the replica is close to the data in the master, the application is paused until the replica is fully synchronized.
  5. Since the data in the source and replica are identical at the end of step 4, the application switches to the replica base.
  6. After some time, having made sure that the new master is stable, you can remove the old database.

Replication is divided into physical and logical

  • In the case of physical replication, data from master to replica is transferred in the same format in which it is stored on drive;
  • In the case of logical replication, data is transferred at a higher level, transferring objects and their changes, rather than just physical data from the drive.

Because of this property, logical replication is cross-versioned, i.e. it allows you to link databases from different major versions (in our case, 9.6 and 12.11). Unfortunately for us, logical replication in PostgreSQL was added only in version 11, so we started looking for third-party replication solutions. Initially, we chose Bucardo because it had been previously used on our projects to migrate a database from Heroku to AWS RDS.

However after some time of studying Bucardo, we came across the pg_logical extension which is very convenient for implementing logical replications and it works on the versions we need. pg_logical works much faster than Bucardo, it doesn’t require any triggers and doesn’t require any third party programs. This is the solution we finally settled on.

Setting up replication

08.06 Migration from PostgreSQL v.9.6 to v.12.11 with minimum downtime img 2 development

Let’s take a closer look at how to set up replication using the pg_logical extension. First, you need to create a new database in AWS RDS as a replica. After that, you need to configure the pg_logical extension in both master and replica. To do this, you need to configure the following parameters using Parameter groups in AWS RDS.

Both in the master and in the replica:

14.06 Migration from PostgreSQL carbon 1 development

In the master:

14.06 Migration from PostgreSQL carbon 2 development

Note that applying a new group of parameters, or changing the current one, will require a restart of the database.

After that we need to connect to the master and replica and configure replication.

14.06 Migration from PostgreSQL carbon 3 development

In order to mark an object as a subject to replication it must be added to the replication set. By default, three replication sets are created when creating an extension:

  • default. For tables in this set all changes are replicated.
  • default_insert_only. Only inserts are replicated for tables in this set. The set may contain tables without primary keys (more about that later).
  • ddl_sql. For tables in this set only DDL changes are replicated, which are specified by `pglogical.replicate_ddl_command`.

Adding to the set is done using a function:

14.06 Migration from PostgreSQL carbon 4 development

Also, for convenience, there is a function that allows you to add all the tables in the scheme:

14.06 Migration from PostgreSQL carbon 5 development

However, after running this function, we discovered that the schema_migrations table that Ruby on Rails created does not contain a primary key. The point is that replication is based on primary key data in WAL. For tables that don’t have a primary key, this is not possible, so for such tables you need to change the writing mechanism in WAL using the following command:

14.06 Migration from PostgreSQL carbon 6 development

Since this table does not contain a primary key and does not change, it can be added to the default_insert_only set:

14.06 Migration from PostgreSQL carbon 7 development

You can use this script to check which tables do not have a primary key:

14.06 Migration from PostgreSQL carbon 8 development


After that, you also need to add sequences to the replicated set:

14.06 Migration from PostgreSQL carbon 9 development

After the master is set up, you need to do that with the replica. First you need to make sure that the master and the replica have the same scheme. This can be done by making a snapshot of it:

14.06 Migration from PostgreSQL carbon 10 development

After that, the pg_logical extension and replication must be configured in the replica:

14.06 Migration from PostgreSQL carbon 11 1 development

After that the replication should be started. You can check this with the following command:

14.06 Migration from PostgreSQL carbon 12 development

This scenario worked without any problems during staging, but the replication eventually crushed in production:

14.06 Migration from PostgreSQL carbon 13 development

Still, we couldn’t find anything meaningful in the logs except for “Connection Timeout”. We tried to change the order of operations: first, creating the replication and then adding tables to the replication set, but these manipulations did not help.

After researching the forums and manuals it was suggested that this problem occurs because there is too much data in the replication queue at the same time.

One of the recommendations is to remove all indexes from the replica scheme and add them again after most of the data is migrated. This will reduce the load on the replica, because when writing into indexed columns we won’t have to specify the index. However, this technique by itself didn’t work. But then accidentally we discovered a working method.

Previously, we used to add all tables to the replicated set at once, but decided to try adding them one at a time within a certain time interval (5-10 minutes). This approach allowed us to successfully replicate all tables.

After most of the data has been replicated, you only need to disable the application and switch the database. In order to check if all the data has been replicated, you can use different methods. We have resorted to one of the simplest: simply counting all rows in the tables and comparing the replica with the master. Since the data between the master and the replica is synchronized at a much faster speed than the database writes, synchronizing the master and the replica took almost no time at all.

14.06 Migration from PostgreSQL carbon 14 1 development


Despite a certain amount of effort and complications, the pg_logical extension allowed us to upgrade a major version of PostgreSQL with minimal downtime (in our case we had to stop the application twice, the total downtime was less than 5 minutes). This approach can be extremely useful for legacy systems with large amounts of data.
